Z2 1974-1978 260Z & 280Z Sequential LED Tail Light Kit

Now Offering Fully Installed Kits!

Note: You will still have to wire in one hot lead to use sequential mode.

The Classic Sequential Tail Light kits are direct retrofit and replacement for incandescent light bulbs in classic vehicles. These kits incorporate high efficiency LED lights that increase tail light brightness, reliability and longevity. The kits replace all the functionality of the light bulbs they replace. This includes low level running light illumination, brake light illumination, turn signal illumination and back-up lighting where applicable. In addition, the kit includes a self-contained microprocessor and circuitry to enable a multitude of sequential lighting patterns. There is no separate sequential lighting control module to mount and wire up. The kit is designed to work with OEM tail light housing and lenses as well as aftermarket components.
NOTE: Tail Light Housings NOT included.

Features

Replaces incandescent bulbs with reliable LEDs
Multiple, user selectable sequential patterns includes at no cost
Simple pushbutton to change sequential patterns
Plug-n-play wiring for simple installation
Works with OEM and aftermarket housings and lenses
Upgradeable programming
Does not draw any power when ignition is Off
Does not compromise sealing of tail light housings
Requires low current draw flasher module, sold separately
Lifetime warranty

Specifications

Number of Sequential Patterns: 8
Standard connections: 1156 & 1157 Bulb Base
Operational Voltage Range: 11.6 to 16.0 volts
Maximum Current Draw (per Panel): 0.16 amps @ 13.8 volts
Number of LEDs (per Panel): 39
Illumination Intensity (per Panel): ~208,000 mcd
Dominant Wavelength: 625 nm

Please contact us with any questions you may have.
